| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TSR1312 | 19 | 19.0 mm 3/4 “ | 32.0 mm 1.26 inch | 350 bar 5070 psi | 1400 bar 20300 psi | 240 mm 9.45 inch | 1.52 kg/mt 1.02 lb/ft | Standard |
| TSR1316 | 25 | 25.4 mm 1 “ | 39.0 mm 1.53 inch | 350 bar 5070 psi | 1400 bar 20300 psi | 300 mm 11.81 inch | 2.02 kg/mt 1.36 lb/ft | Standard |
| TSR1320 | 31 | 31.8 mm 1 1/4 “ | 49.5 mm 1.95 inch | 350 bar 5070 psi | 1400 bar 20300 psi | 420 mm 16.54 inch | 3.33 kg/mt 2.24 lb/ft | Standard |
| TSR1324 | 38 | 38.1 mm 1 1/2 “ | 57.8 mm 2.27 inch | 350 bar 5070 psi | 1400 bar 20300 psi | 500 mm 19.69 inch | 4.31 kg/mt 2.90 lb/ft | Standard |
| TSR1332 | 51 | 50.8 mm 2 “ | 71.6 mm 2.82 inch | 350 bar 5070 psi | 1400 bar 20300 psi | 630 mm 24.80 inch | 6.32 kg/mt 4.25 lb/ft | Standard |
