| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Wall thickness | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|---|
| THFHM02 | 3 | 3.2 mm 1/8 “ | 6.5 mm 0.26 inch | 275 bar 3988 psi | 1100 bar 15950 psi | 25 mm 0.98 inch | 1.00 mm 39.000 inch | 0.07 kg/mt 0.05 lb/ft | Standard |
| THFHM03 | 5 | 4.8 mm 3/16 “ | 7.8 mm 0.31 inch | 200 bar 2900 psi | 800 bar 11600 psi | 35 mm 1.38 inch | 0.90 mm 35.000 inch | 0.09 kg/mt 0.06 lb/ft | Standard |
| THFHM04 | 6 | 6.4 mm 1/4 “ | 9.4 mm 0.37 inch | 175 bar 2538 psi | 700 bar 10150 psi | 45 mm 1.77 inch | 0.90 mm 35.000 inch | 0.11 kg/mt 0.07 lb/ft | Standard |
| THFHM05 | 8 | 7.9 mm 5/16 “ | 11.2 mm 0.44 inch | 150 bar 2175 psi | 600 bar 8700 psi | 50 mm 1.97 inch | 0.90 mm 35.000 inch | 0.15 kg/mt 0.10 lb/ft | Standard |
| THFHM06 | 10 | 9.5 mm 3/8 “ | 12.8 mm 0.50 inch | 135 bar 1958 psi | 540 bar 7830 psi | 55 mm 2.16 inch | 0.90 mm 35.000 inch | 0.17 kg/mt 0.12 lb/ft | Standard |
| THFHM08 | 12 | 12.7 mm 1/2 “ | 16.0 mm 0.63 inch | 120 bar 1740 psi | 480 bar 6960 psi | 70 mm 2.75 inch | 0.90 mm 35.000 inch | 0.24 kg/mt 0.16 lb/ft | Standard |
| THFHM10 | 16 | 15.9 mm 5/8 “ | 19.2 mm 0.76 inch | 100 bar 1450 psi | 400 bar 5800 psi | 130 mm 5.11 inch | 0.90 mm 35.000 inch | 0.30 kg/mt 0.20 lb/ft | Standard |
| THFHM12 | 19 | 19.0 mm 3/4 “ | 22.5 mm 0.89 inch | 90 bar 1305 psi | 360 bar 5220 psi | 190 mm 7.47 inch | 1.00 mm 39.000 inch | 0.37 kg/mt 0.25 lb/ft | Standard |
| THFHM16 | 25 | 25.4 mm 1 “ | 29.4 mm 1.16 inch | 65 bar 943 psi | 260 bar 3770 psi | 270 mm 10.62 inch | 1.10 mm 43.000 inch | 0.50 kg/mt 0.34 lb/ft | Standard |
