| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH1TER603 | 5 | 4.8 mm 3/16 “ | 11.0 mm 0.43 inch | 35 bar 507 psi | 140 bar 2030 psi | 35 mm 1.38 inch | 0.10 kg/mt 0.06 lb/ft | Standard |
| TH1TER604 | 6 | 6.4 mm 1/4 “ | 12.6 mm 0.50 inch | 28 bar 406 psi | 112 bar 1624 psi | 45 mm 1.77 inch | 0.12 kg/mt 0.08 lb/ft | Standard |
| TH1TER605 | 8 | 7.9 mm 5/16 “ | 14.0 mm 0.55 inch | 28 bar 406 psi | 112 bar 1624 psi | 65 mm 2.56 inch | 0.13 kg/mt 0.09 lb/ft | Standard |
| TH1TER606 | 10 | 9.5 mm 3/8 “ | 15.8 mm 0.62 inch | 28 bar 406 psi | 112 bar 1624 psi | 75 mm 2.95 inch | 0.16 kg/mt 0.10 lb/ft | Standard |
| TH1TER608 | 12 | 12.8 mm 1/2 “ | 19.4 mm 0.76 inch | 28 bar 406 psi | 112 bar 1624 psi | 90 mm 3.54 inch | 0.21 kg/mt 0.14 lb/ft | Standard |
| TH1TER610 | 16 | 16.0 mm 5/8 “ | 23.0 mm 0.91 inch | 24 bar 348 psi | 96 bar 1392 psi | 115 mm 4.52 inch | 0.27 kg/mt 0.18 lb/ft | Standard |
| TH1TER612 | 19 | 19.0 mm 3/4 “ | 26.0 mm 1.02 inch | 21 bar 305 psi | 84 bar 1218 psi | 140 mm 5.51 inch | 0.32 kg/mt 0.21 lb/ft | Standard |
| TH1TER616 | 25 | 25.4 mm 1 “ | 33.0 mm 1.30 inch | 20 bar 290 psi | 80 bar 1160 psi | 150 mm 5.91 inch | 0.48 kg/mt 0.32 lb/ft | Standard |
