| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TJ2SN04P | 6 | 6.4 mm 1/4 “ | 14.6 mm 0.57 inch | 600 bar 8700 psi | 1800 bar 26100 psi | 100 mm 3.93 inch | 0.36 kg/mt 0.24 lb/ft | Standard |
| TJ2SN05P | 8 | 7.9 mm 5/16 “ | 16.3 mm 0.64 inch | 600 bar 8700 psi | 1800 bar 26100 psi | 115 mm 4.53 inch | 0.43 kg/mt 0.29 lb/ft | Standard |
| TJ2SN06P | 10 | 9.5 mm 3/8 “ | 18.7 mm 0.74 inch | 600 bar 8700 psi | 1800 bar 26100 psi | 130 mm 5.12 inch | 0.56 kg/mt 0.38 lb/ft | Standard |
| TJ2SN08P | 12 | 12.8 mm 1/2 “ | 22.2 mm 0.87 inch | 600 bar 8700 psi | 1800 bar 26100 psi | 160 mm 6.29 inch | 0.63 kg/mt 0.42 lb/ft | Standard |
