Kods | F1 inch | H1 mm | L mm | L1 mm | Spiediens |
---|---|---|---|---|---|
ABFDG02 | 1/8 | 14 | 35.50 | 30.50 | 350 bar 5075 psi |
ABFDG04 | 1/4 | 19 | 49.50 | 43.00 | 350 bar 5075 psi |
ABFDG06 | 3/8 | 22 | 58.00 | 50.50 | 350 bar 5075 psi |
ABFDG08 | 1/2 | 27 | 73.00 | 64.00 | 315 bar 4568 psi |
ABFDG10 | 5/8 | 30 | 74.50 | 66.50 | 315 bar 4568 psi |
ABFDG12 | 3/4 | 32 | 92.00 | 81.00 | 250 bar 3625 psi |
ABFDG16 | 1 | 41 | 110.00 | 96.00 | 200 bar 2900 psi |
ABFDG20 | 1 1/4 | 50 | – | – | 160 bar 2320 psi |
ABFDG24 | 1 1/2 | 55 | – | – | 125 bar 1813 psi |
