Hydraulic Constant Working Pressure Hose 1000 PSI - GlobalCore 187 Hose

Brand : Parker Hannifin

The newest member of the GlobalCore hose product family, 187 high pressure hydraulic hose is engineered to meet and exceed ISO 18752 performance specifications. A product that’s unmatched in today’s marketplace, GlobalCore 187 hose is the first and only 1,000 PSI constant working pressure hydraulic hose offered in sizes from -8 through -48 (1/2” through 3” inner diameter). Tested to twice the requirements of the ISO 18752 standard, GlobalCore 187 hose is designed to excel in rugged environments and high impulse applications. Like other GlobalCore hoses, high performance 187 hose offers low force to flex and a superior bend radius. Constructed with a synthetic rubber inner tube for a wider range of fluid compatibilities, and reinforced with one- or two-braid steel wire, 187 hose is designed to be a robust and reliable hydraulic hose solution. Choose from three cover options — Standard, Tough, and SuperTough — to match the level of abrasion resistance needed for each application.

Markets:
• Transportation
• Military
• Construction
• Agriculture
• Grounds & Building Maintenance
• Waste & Refuse
• Material Handling
• Forestry
• Railroad
• Utility Equipment
• Personnel Lift Equipment
• Machine Tool
• Aftermarket
• Industrial
• Mining

Features/Benefits:
• Standard, ToughCover or SuperTough cover options to prevent abrasion
• Half SAE bend radius for ease of installation and low force to flex (up to -32)
• 1000 PSI constant working pressure in all sizes
• Exceeds ISO 18752 performance specification (AC and AS)
• Synthetic rubber inner tube provides a wider range of fluid compatibility

Applications:
• Petroleum base hydraulic fluids and lubricating oils

Compatible Fittings:
• 43 series fittings



Minimum Operating Temperature:-40 °C, -40 °F
Media:Lubricants, Petroleum Hydraulic Fluids
Specifications Met:ISO 18752, MSHA TC & ST covers only
Compatible Fitting:43 Series
Weight:0.29 to 2.77 lb/ft, 0.43 to 4.12 kg/m
Inside Diameter:1/2 to 3 inch, 12.5 to 76 mm
Size:-8 to -48
Maximum Operating Temperature:100 °C (TC & ST), 125 °C (TC & ST), 212 °F (TC & ST, except -40 & -48), 257 °F (TC & ST, except -40 & -48)
Maximum Operating Pressure:7.0 MPa, 1000 psi, 70 bar
Application:Agriculture Equipment, Construction Equipment, Forestry, Hydraulics, Industrial, Material Handling, Transportation, Vacuum
Hose Reinforcement Material:1 or 2 Braids of Steel Wire
Vacuum Pressure Rating:18 to 24 inch-Hg, 60 to 80 kPa, 457.2 to 609.6 mm-Hg
Minimum Bend Radius:2-1/2 to 20 inch, 65 to 508 mm
Outside Diameter:0.81 to 3.58 inch, 21 to 91 mm
Nominal Hose Inside Diameter:13 to 76 mm
Hose Inner Tube Material:Synthetic Rubber
Cover Material:Synthetic Rubber



ProductsHose I.D. (size)Hose Cover Type
187-40-40Standard
187TC-40-40ToughCover
187ST-40-40SuperTough
187-48-48Standard
187TC-48-48ToughCover
187-8-8Standard
187TC-8-8ToughCover
187ST-8-8SuperTough
187-10-10Standard
187TC-10-10ToughCover
187ST-10-10SuperTough
187-12-12Standard
187TC-12-12ToughCover
187ST-12-12SuperTough
187ST-48-48SuperTough
