| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TS4SH10 | 16 | 16.0 mm 5/8 “ | 28.5 mm 1.12 inch | 450 bar 6525 psi | 1800 bar 26100 psi | 240 mm 9.44 inch | 1.39 kg/mt 0.93 lb/ft | Standard |
| TS4SH12 | 19 | 19.0 mm 3/4 “ | 31.2 mm 1.23 inch | 420 bar 6090 psi | 1680 bar 24360 psi | 280 mm 11.02 inch | 1.46 kg/mt 0.98 lb/ft | Standard |
| TS4SH16 | 25 | 25.4 mm 1 “ | 38.3 mm 1.51 inch | 385 bar 5580 psi | 1540 bar 22320 psi | 340 mm 13.39 inch | 1.95 kg/mt 1.31 lb/ft | Standard |
| TS4SH20 | 31 | 31.8 mm 1 1/4 “ | 45.4 mm 1.79 inch | 350 bar 5070 psi | 1400 bar 20280 psi | 460 mm 18.11 inch | 2.45 kg/mt 1.65 lb/ft | Standard |
| TS4SH24 | 38 | 38.1 mm 1 1/2 “ | 53.0 mm 2.08 inch | 300 bar 4350 psi | 1200 bar 17400 psi | 560 mm 22.05 inch | 3.00 kg/mt 2.02 lb/ft | Standard |
| TS4SH32 | 51 | 50.8 mm 2 “ | 67.6 mm 2.66 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 700 mm 27.56 inch | 4.31 kg/mt 2.90 lb/ft | Standard |
