| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| THMTH103 | 5 | 4.8 mm 3/16 “ | 10.0 mm 0.39 inch | 325 bar 4713 psi | 1300 bar 18850 psi | 30 mm 1.18 inch | 0.13 kg/mt 0.09 lb/ft | Standard |
| THMTH104 | 6 | 6.4 mm 1/4 “ | 11.9 mm 0.47 inch | 300 bar 4350 psi | 1200 bar 17400 psi | 40 mm 1.57 inch | 0.17 kg/mt 0.11 lb/ft | Standard |
| THMTH105 | 8 | 8.0 mm 5/16 “ | 14.0 mm 0.55 inch | 240 bar 3480 psi | 960 bar 13920 psi | 50 mm 1.97 inch | 0.22 kg/mt 0.15 lb/ft | Standard |
| THMTH106 | 10 | 9.7 mm 3/8 “ | 16.0 mm 0.63 inch | 225 bar 3263 psi | 900 bar 13050 psi | 60 mm 2.36 inch | 0.26 kg/mt 0.17 lb/ft | Standard |
| THMTH108 | 12 | 13.0 mm 1/2 “ | 19.2 mm 0.76 inch | 190 bar 2755 psi | 760 bar 11020 psi | 75 mm 2.95 inch | 0.33 kg/mt 0.22 lb/ft | Standard |
| THMTH110 | 16 | 16.0 mm 5/8 “ | 23.3 mm 0.92 inch | 150 bar 2175 psi | 600 bar 8700 psi | 110 mm 4.33 inch | 0.41 kg/mt 0.28 lb/ft | Standard |
| THMTH112 | 19 | 19.2 mm 3/4 “ | 25.5 mm 1.00 inch | 130 bar 1885 psi | 520 bar 7540 psi | 150 mm 5.90 inch | 0.45 kg/mt 0.31 lb/ft | Standard |
| THMTH116 | 25 | 25.6 mm 1 “ | 32.5 mm 1.28 inch | 105 bar 1523 psi | 420 bar 6090 psi | 185 mm 7.28 inch | 0.59 kg/mt 0.40 lb/ft | Standard |
| THMTH120 | 31 | 31.8 mm 1 1/4 “ | 40.0 mm 1.57 inch | 70 bar 1015 psi | 280 bar 4060 psi | 290 mm 11.40 inch | 0.89 kg/mt 0.60 lb/ft | Standard |
