| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TSER406 | 10 | 9.5 mm 3/8 “ | 19.9 mm 0.78 inch | 280 bar 4000 psi | 1120 bar 16000 psi | 65 mm 2.56 inch | 0.57 kg/mt 0.38 lb/ft | Standard |
| TSER408 | 12 | 12.8 mm 1/2 “ | 23.0 mm 0.90 inch | 280 bar 4000 psi | 1120 bar 16000 psi | 90 mm 3.54 inch | 0.77 kg/mt 0.52 lb/ft | Standard |
| TSER410 | 16 | 16.0 mm 5/8 “ | 27.0 mm 1.06 inch | 280 bar 4000 psi | 1120 bar 16000 psi | 100 mm 3.94 inch | 0.97 kg/mt 0.63 lb/ft | Standard |
| TSER412 | 19 | 19.0 mm 3/4 “ | 30.1 mm 1.18 inch | 280 bar 4000 psi | 1120 bar 16000 psi | 120 mm 4.72 inch | 1.30 kg/mt 0.87 lb/ft | Standard |
| TSER416 | 25 | 25.4 mm 1 “ | 37.8 mm 1.49 inch | 280 bar 4000 psi | 1120 bar 16000 psi | 150 mm 5.90 inch | 1.77 kg/mt 1.19 lb/ft | Standard |
