| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TH1SC04 | 6 | 6.4 mm 1/4 “ | 12.2 mm 0.48 inch | 225 bar 3260 psi | 900 bar 13040 psi | 75 mm 2.95 inch | 0.17 kg/mt 0.11 lb/ft | Standard |
| TH1SC05 | 8 | 7.9 mm 5/16 “ | 13.5 mm 0.53 inch | 215 bar 3110 psi | 860 bar 12440 psi | 85 mm 3.34 inch | 0.22 kg/mt 0.15 lb/ft | Standard |
| TH1SC06 | 10 | 9.5 mm 3/8 “ | 15.6 mm 0.61 inch | 180 bar 2610 psi | 720 bar 10440 psi | 90 mm 3.54 inch | 0.26 kg/mt 0.17 lb/ft | Standard |
| TH1SC08 | 12 | 12.8 mm 1/2 “ | 19.1 mm 0.75 inch | 160 bar 2320 psi | 640 bar 9280 psi | 130 mm 5.11 inch | 0.36 kg/mt 0.24 lb/ft | Standard |
| TH1SC10 | 16 | 16.0 mm 5/8 “ | 22.4 mm 0.88 inch | 130 bar 1880 psi | 520 bar 7520 psi | 170 mm 6.69 inch | 0.45 kg/mt 0.30 lb/ft | Standard |
| TH1SC12 | 19 | 19.0 mm 3/4 “ | 26.0 mm 1.02 inch | 105 bar 1520 psi | 420 bar 6080 psi | 200 mm 7.87 inch | 0.53 kg/mt 0.36 lb/ft | Standard |
| TH1SC16 | 25 | 25.4 mm 1 “ | 33.4 mm 1.31 inch | 88 bar 1270 psi | 352 bar 5080 psi | 250 mm 9.84 inch | 0.77 kg/mt 0.52 lb/ft | Standard |
| TH1SC20 | 31 | 31.8 mm 1 1/4 “ | 40.9 mm 1.61 inch | 63 bar 910 psi | 252 bar 3640 psi | 250 mm 9.83 inch | 0.99 kg/mt 0.67 lb/ft | Standard |
| TH1SC24 | 38 | 38.1 mm 1 1/2 “ | 47.5 mm 1.87 inch | 50 bar 720 psi | 200 bar 2880 psi | 300 mm 11.81 inch | 1.25 kg/mt 0.84 lb/ft | Standard |
| TH1SC32 | 51 | 50.8 mm 2 “ | 60.5 mm 2.38 inch | 40 bar 580 psi | 160 bar 2320 psi | 400 mm 15.14 inch | 1.60 kg/mt 1.08 lb/ft | Standard |
