| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TH2SC04P | 6 | 6.4 mm 1/4 “ | 13.3 mm 0.52 inch | 420 bar 6100 psi | 1680 bar 24400 psi | 45 mm 1.77 inch | 0.30 kg/mt 0.20 lb/ft | Standard |
| TH2SC05P | 8 | 7.9 mm 5/16 “ | 14.9 mm 0.59 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 55 mm 2.17 inch | 0.34 kg/mt 0.23 lb/ft | Standard |
| TH2SC06P | 10 | 9.5 mm 3/8 “ | 17.0 mm 0.67 inch | 350 bar 5100 psi | 1400 bar 20400 psi | 65 mm 2.56 inch | 0.41 kg/mt 0.28 lb/ft | Standard |
| TH2SC08P | 12 | 12.8 mm 1/2 “ | 20.4 mm 0.80 inch | 310 bar 4500 psi | 1240 bar 18000 psi | 80 mm 3.15 inch | 0.52 kg/mt 0.35 lb/ft | Standard |
| TH2SC10P | 16 | 16.0 mm 5/8 “ | 23.8 mm 0.94 inch | 280 bar 4100 psi | 1120 bar 16400 psi | 90 mm 3.54 inch | 0.68 kg/mt 0.46 lb/ft | Standard |
| TH2SC12P | 19 | 19.0 mm 3/4 “ | 27.5 mm 1.08 inch | 270 bar 3910 psi | 1080 bar 15660 psi | 120 mm 4.72 inch | 0.85 kg/mt 0.57 lb/ft | Standard |
| TH2SC16P | 25 | 25.4 mm 1 “ | 35.3 mm 1.39 inch | 210 bar 3045 psi | 840 bar 12180 psi | 160 mm 6.30 inch | 1.18 kg/mt 0.79 lb/ft | Standard |
| TH2SC20P | 31 | 31.8 mm 1 1/4 “ | 43.1 mm 1.70 inch | 170 bar 2465 psi | 680 bar 9860 psi | 250 mm 9.84 inch | 1.56 kg/mt 1.05 lb/ft | Standard |
