| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH1SN03SL | 5 | 4.8 mm 3/16 “ | 9.9 mm 0.39 inch | 125 bar 1810 psi | 500 bar 7250 psi | 20 mm 0.79 inch | 0.10 kg/mt 0.07 lb/ft | Standard |
| TH1SN04SL | 6 | 6.4 mm 1/4 “ | 11.5 mm 0.45 inch | 125 bar 1810 psi | 500 bar 7250 psi | 25 mm 0.98 inch | 0.12 kg/mt 0.08 lb/ft | Standard |
| TH1SN05SL | 8 | 7.9 mm 5/16 “ | 13.1 mm 0.52 inch | 125 bar 1810 psi | 500 bar 7250 psi | 30 mm 1.18 inch | 0.16 kg/mt 0.11 lb/ft | Standard |
| TH1SN06SL | 10 | 9.5 mm 3/8 “ | 14.8 mm 0.58 inch | 125 bar 1810 psi | 500 bar 7250 psi | 40 mm 1.57 inch | 0.20 kg/mt 0.13 lb/ft | Standard |
| TH1SN08SL | 12 | 12.8 mm 1/2 “ | 18.5 mm 0.73 inch | 125 bar 1810 psi | 500 bar 7250 psi | 50 mm 1.97 inch | 0.27 kg/mt 0.18 lb/ft | Standard |
| TH1SN10SL | 16 | 16.0 mm 5/8 “ | 21.4 mm 0.99 inch | 125 bar 1810 psi | 500 bar 7250 psi | 65 mm 1.97 inch | 0.33 kg/mt 0.22 lb/ft | Standard |
| TH1SN12SL | 19 | 19.0 mm 3/4 “ | 25.0 mm 0.98 inch | 125 bar 1810 psi | 500 bar 7250 psi | 80 mm 3.15 inch | 0.46 kg/mt 0.31 lb/ft | Standard |
| TH1SN16SL | 25 | 25.4 mm 1 “ | 31.4 mm 1.24 inch | 125 bar 1810 psi | 500 bar 7250 psi | 120 mm 4.72 inch | 0.59 kg/mt 0.40 lb/ft | Standard |
