| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH1SC04SC | 6 | 6.4 mm 1/4 “ | 12.4 mm 0.49 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 75 mm 2.95 inch | 0.19 kg/mt 0.13 lb/ft | Standard |
| TH1SC05SC | 8 | 7.9 mm 5/16 “ | 13.5 mm 0.53 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 87 mm 3.35 inch | 0.22 kg/mt 0.15 lb/ft | Standard |
| TH1SC06SC | 10 | 9.5 mm 3/8 “ | 15.6 mm 0.61 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 90 mm 3.54 inch | 0.29 kg/mt 0.19 lb/ft | Standard |
| TH1SC08SC | 12 | 12.8 mm 1/2 “ | 19.1 mm 0.75 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 130 mm 5.12 inch | 0.37 kg/mt 0.25 lb/ft | Standard |
