| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH2ST04M | 6 | 6.4 mm 1/4 “ | 17.5 mm 0.69 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 100 mm 3.93 inch | 0.42 kg/mt 0.28 lb/ft | Standard |
| TH2ST06M | 10 | 9.5 mm 3/8 “ | 21.4 mm 0.84 inch | 345 bar 5000 psi | 1380 bar 20010 psi | 130 mm 5.11 inch | 0.61 kg/mt 0.41 lb/ft | Standard |
| TH2ST08M | 12 | 12.8 mm 1/2 “ | 24.6 mm 0.97 inch | 295 bar 4280 psi | 1180 bar 17110 psi | 150 mm 5.90 inch | 0.74 kg/mt 0.50 lb/ft | Standard |
| TH2ST12M | 19 | 19.0 mm 3/4 “ | 31.8 mm 1.25 inch | 280 bar 4060 psi | 1120 bar 16240 psi | 230 mm 9.05 inch | 1.18 kg/mt 0.79 lb/ft | Standard |
| TH2ST16M | 25 | 25.4 mm 1 “ | 38.3 mm 1.51 inch | 280 bar 4060 psi | 1120 bar 16240 psi | 300 mm 11.80 inch | 1.54 kg/mt 1.03 lb/ft | Standard |
