| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH1SC12LP | 19 | 19.0 mm 3/4 “ | 26.0 mm 1.02 inch | 50 bar 725 psi | 450 bar 6520 psi | 100 mm 3.94 inch | 0.54 kg/mt 0.36 lb/ft | Standard |
| TH1SC16LP | 25 | 25.4 mm 1 “ | 33.4 mm 1.31 inch | 50 bar 725 psi | 450 bar 6520 psi | 160 mm 6.30 inch | 0.82 kg/mt 0.55 lb/ft | Standard |
| TH1SC20LP | 31 | 31.8 mm 1 1/4 “ | 40.9 mm 1.61 inch | 50 bar 725 psi | 450 bar 6520 psi | 210 mm 8.27 inch | 1.08 kg/mt 0.73 lb/ft | Standard |
| TH2SC24LP | 38 | 38.1 mm 1 1/2 “ | 49.8 mm 1.96 inch | 50 bar 725 psi | 450 bar 6520 psi | 300 mm 11.81 inch | 1.75 kg/mt 1.18 lb/ft | Standard |
| TH2SC32LP | 51 | 50.8 mm 2 “ | 63.4 mm 2.50 inch | 45 bar 650 psi | 400 bar 5800 psi | 400 mm 15.75 inch | 2.45 kg/mt 1.65 lb/ft | Standard |
