| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TB4SP06P | 10 | 9.5 mm 3/8 “ | 21.6 mm 0.85 inch | 1250 bar 18120 psi | 3125 bar 45310 psi | 230 mm 9.06 inch | 0.87 kg/mt 0.58 lb/ft | Standard |
| TB4SP08P | 12 | 12.8 mm 1/2 “ | 24.5 mm 0.96 inch | 1100 bar 15950 psi | 2750 bar 39870 psi | 230 mm 9.06 inch | 1.13 kg/mt 0.76 lb/ft | Standard |
| TB4SP12P | 19 | 19.0 mm 3/4 “ | 32.0 mm 1.26 inch | 1000 bar 14500 psi | 2500 bar 36250 psi | 250 mm 9.84 inch | 1.69 kg/mt 1.14 lb/ft | Standard |
| TB4SP16P | 25 | 24.4 mm 1 “ | 38.1 mm 1.50 inch | 700 bar 10150 psi | 1750 bar 25370 psi | 260 mm 10.23 inch | 2.04 kg/mt 1.37 lb/ft | Standard |
