| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TJ2SC04 | 6 | 6.4 mm 1/4 “ | 13.4 mm 0.53 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 75 mm 2.95 inch | 0.27 kg/mt 0.18 lb/ft | Standard |
| TJ2SC05 | 8 | 7.9 mm 5/16 “ | 15.0 mm 0.59 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 85 mm 3.34 inch | 0.32 kg/mt 0.22 lb/ft | Standard |
| TJ2SC06 | 10 | 9.5 mm 3/8 “ | 17.0 mm 0.67 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 90 mm 3.54 inch | 0.40 kg/mt 0.27 lb/ft | Standard |
| TJ2SC08 | 12 | 12.8 mm 1/2 “ | 20.4 mm 0.80 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 130 mm 5.11 inch | 0.54 kg/mt 0.36 lb/ft | Standard |
