| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| THR703 | 5 | 4.8 mm 3/16 “ | 10.0 mm 0.39 inch | 210 bar 3045 psi | 840 bar 12180 psi | 30 mm 1.18 inch | 0.07 kg/mt 0.05 lb/ft | Standard |
| THR704 | 6 | 6.4 mm 1/4 “ | 11.8 mm 0.46 inch | 200 bar 2900 psi | 800 bar 11600 psi | 35 mm 1.38 inch | 0.09 kg/mt 0.06 lb/ft | Standard |
| THR705 | 8 | 8.0 mm 5/16 “ | 14.3 mm 0.56 inch | 190 bar 2755 psi | 760 bar 11020 psi | 45 mm 1.77 inch | 0.13 kg/mt 0.09 lb/ft | Standard |
| THR706 | 10 | 9.7 mm 3/8 “ | 16.0 mm 0.63 inch | 175 bar 2538 psi | 700 bar 10150 psi | 55 mm 2.16 inch | 0.16 kg/mt 0.10 lb/ft | Standard |
| THR708 | 12 | 13.0 mm 1/2 “ | 20.3 mm 0.80 inch | 140 bar 2030 psi | 560 bar 8120 psi | 75 mm 2.95 inch | 0.22 kg/mt 0.15 lb/ft | Standard |
| THR710 | 16 | 16.0 mm 5/8 “ | 23.5 mm 0.92 inch | 105 bar 1523 psi | 420 bar 6090 psi | 120 mm 4.72 inch | 0.28 kg/mt 0.19 lb/ft | Standard |
| THR712 | 19 | 19.2 mm 3/4 “ | 26.5 mm 1.04 inch | 90 bar 1305 psi | 360 bar 5220 psi | 145 mm 5.70 inch | 0.33 kg/mt 0.22 lb/ft | Standard |
| THR716 | 25 | 25.6 mm 1 “ | 33.6 mm 1.32 inch | 70 bar 1015 psi | 280 bar 4060 psi | 200 mm 7.87 inch | 0.40 kg/mt 0.27 lb/ft | Standard |
