| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| THMTKH04 | 6 | 6.4 mm 1/4 “ | 14.5 mm 0.57 inch | 700 bar 10150 psi | 2800 bar 40600 psi | 40 mm 1.57 inch | 0.26 kg/mt 0.17 lb/ft | Standard |
| THMTKH06 | 10 | 9.5 mm 3/8 “ | 18.0 mm 0.71 inch | 425 bar 6163 psi | 1700 bar 24650 psi | 60 mm 2.36 inch | 0.34 kg/mt 0.23 lb/ft | Standard |
| THMTKH08 | 12 | 13.0 mm 1/2 “ | 22.0 mm 0.87 inch | 375 bar 5438 psi | 1500 bar 21750 psi | 75 mm 2.95 inch | 0.46 kg/mt 0.31 lb/ft | Standard |
| THMTKH12 | 19 | 19.2 mm 3/4 “ | 28.2 mm 1.11 inch | 225 bar 3263 psi | 900 bar 13050 psi | 150 mm 5.90 inch | 0.66 kg/mt 0.44 lb/ft | Standard |
| THMTKH16 | 25 | 25.8 mm 1 “ | 35.4 mm 1.39 inch | 200 bar 2900 psi | 800 bar 11600 psi | 250 mm 9.84 inch | 0.86 kg/mt 0.58 lb/ft | Standard |
