| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
| TH1SN03 | 5 | 4.8 mm 3/16 “ | 11.5 mm 0.45 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 90 mm 3.54 inch | 0.17 kg/mt 0.11 lb/ft | Standard |
| TH1SN04 | 6 | 6.4 mm 1/4 “ | 13.1 mm 0.52 inch | 225 bar 3260 psi | 900 bar 13040 psi | 100 mm 3.94 inch | 0.21 kg/mt 0.14 lb/ft | Standard |
| TH1SN05 | 8 | 7.9 mm 5/16 “ | 14.7 mm 0.58 inch | 215 bar 3110 psi | 860 bar 12440 psi | 115 mm 4.53 inch | 0.26 kg/mt 0.17 lb/ft | Standard |
| TH1SN06 | 10 | 9.5 mm 3/8 “ | 17.1 mm 0.67 inch | 180 bar 2610 psi | 720 bar 10440 psi | 130 mm 5.12 inch | 0.32 kg/mt 0.22 lb/ft | Standard |
| TH1SN08 | 12 | 12.8 mm 1/2 “ | 20.2 mm 0.80 inch | 160 bar 2320 psi | 640 bar 9280 psi | 180 mm 7.09 inch | 0.40 kg/mt 0.27 lb/ft | Standard |
| TH1SN10 | 16 | 16.0 mm 5/8 “ | 23.4 mm 0.92 inch | 130 bar 1880 psi | 520 bar 7520 psi | 200 mm 7.87 inch | 0.48 kg/mt 0.32 lb/ft | Standard |
| TH1SN12 | 19 | 19.0 mm 3/4 “ | 27.4 mm 1.08 inch | 105 bar 1520 psi | 420 bar 6080 psi | 240 mm 9.45 inch | 0.60 kg/mt 0.40 lb/ft | Standard |
| TH1SN16 | 25 | 25.4 mm 1 “ | 35.3 mm 1.39 inch | 88 bar 1270 psi | 352 bar 5080 psi | 300 mm 11.81 inch | 0.92 kg/mt 0.62 lb/ft | Standard |
| TH1SN20 | 31 | 31.8 mm 1 1/4 “ | 42.9 mm 1.69 inch | 63 bar 910 psi | 252 bar 3620 psi | 420 mm 16.54 inch | 1.20 kg/mt 0.81 lb/ft | Standard |
| TH1SN24 | 38 | 38.1 mm 1 1/2 “ | 50.1 mm 1.97 inch | 50 bar 720 psi | 200 bar 2880 psi | 500 mm 19.69 inch | 1.46 kg/mt 0.98 lb/ft | Standard |
| TH1SN32 | 51 | 50.8 mm 2 “ | 63.4 mm 2.50 inch | 40 bar 580 psi | 160 bar 2320 psi | 630 mm 24.80 inch | 2.04 kg/mt 1.37 lb/ft | Standard |
