| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH2SN03V2 | 5 | 4.8 mm 3/16 “ | 13.3 mm 0.52 inch | 415 bar 6010 psi | 1660 bar 24040 psi | 90 mm 3.54 inch | 0.28 kg/mt 0.19 lb/ft | Standard |
| TH2SN04V2 | 6 | 6.4 mm 1/4 “ | 15.1 mm 0.59 inch | 400 bar 5800 psi | 1600 bar 23200 psi | 100 mm 3.94 inch | 0.35 kg/mt 0.24 lb/ft | Standard |
| TH2SN05V2 | 8 | 7.9 mm 5/16 “ | 16.8 mm 0.66 inch | 350 bar 5070 psi | 1400 bar 20280 psi | 115 mm 4.53 inch | 0.46 kg/mt 0.31 lb/ft | Standard |
| TH2SN06V2 | 10 | 9.5 mm 3/8 “ | 19.1 mm 0.75 inch | 330 bar 4780 psi | 1320 bar 19120 psi | 130 mm 5.12 inch | 0.56 kg/mt 0.38 lb/ft | Standard |
| TH2SN08V2 | 12 | 12.8 mm 1/2 “ | 22.3 mm 0.88 inch | 275 bar 3980 psi | 1100 bar 15920 psi | 180 mm 7.09 inch | 0.65 kg/mt 0.44 lb/ft | Standard |
| TH2SN10V2 | 16 | 16.0 mm 5/8 “ | 25.5 mm 1.00 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 200 mm 7.87 inch | 0.80 kg/mt 0.54 lb/ft | Standard |
| TH2SN12V2 | 19 | 19.0 mm 3/4 “ | 29.5 mm 1.16 inch | 215 bar 3110 psi | 860 bar 12440 psi | 240 mm 9.45 inch | 1.00 kg/mt 0.67 lb/ft | Standard |
| TH2SN16V2 | 25 | 25.4 mm 1 “ | 37.6 mm 1.48 inch | 165 bar 2390 psi | 660 bar 9560 psi | 300 mm 11.81 inch | 1.38 kg/mt 0.93 lb/ft | Standard |
| TH2SN20V2 | 31 | 31.8 mm 1 1/4 “ | 47.3 mm 1.86 inch | 125 bar 1810 psi | 500 bar 7240 psi | 420 mm 16.54 inch | 2.00 kg/mt 1.34 lb/ft | Standard |
| TH2SN24V2 | 38 | 38.1 mm 1 1/2 “ | 53.8 mm 2.12 inch | 100 bar 1450 psi | 400 bar 5800 psi | 500 mm 19.69 inch | 2.30 kg/mt 1.55 lb/ft | Standard |
| TH2SN32V2 | 51 | 50.8 mm 2 “ | 66.5 mm 2.62 inch | 90 bar 1305 psi | 360 bar 5220 psi | 630 mm 24.80 inch | 3.00 kg/mt 2.02 lb/ft | Standard |
