| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH2SC04PRE | 6 | 6.4 mm 1/4 “ | 13.3 mm 0.52 inch | 450 bar 6500 psi | 1800 bar 26100 psi | 45 mm 1.77 inch | 0.29 kg/mt 0.19 lb/ft | Standard |
| TH2SC05PRE | 8 | 7.9 mm 5/16 “ | 14.7 mm 0.58 inch | 425 bar 6100 psi | 1700 bar 24650 psi | 55 mm 2.17 inch | 0.32 kg/mt 0.22 lb/ft | Standard |
| TH2SC06PRE | 10 | 9.5 mm 3/8 “ | 17.0 mm 0.67 inch | 390 bar 5600 psi | 1560 bar 22600 psi | 65 mm 2.56 inch | 0.42 kg/mt 0.28 lb/ft | Standard |
| TH2SC08PRE | 12 | 12.8 mm 1/2 “ | 20.4 mm 0.80 inch | 350 bar 5100 psi | 1400 bar 20300 psi | 80 mm 3.15 inch | 0.56 kg/mt 0.38 lb/ft | Standard |
| TH2SC10PRE | 16 | 16.0 mm 5/8 “ | 24.5 mm 0.96 inch | 350 bar 5100 psi | 1400 bar 20300 psi | 90 mm 3.54 inch | 0.74 kg/mt 0.50 lb/ft | Standard |
| TH2SC12PRE | 19 | 19.0 mm 3/4 “ | 27.5 mm 1.08 inch | 300 bar 4300 psi | 1200 bar 17400 psi | 120 mm 4.72 inch | 0.84 kg/mt 0.56 lb/ft | Standard |
| TH2SC16PRE | 25 | 25.4 mm 1 “ | 35.3 mm 1.39 inch | 230 bar 3335 psi | 920 bar 13300 psi | 160 mm 6.30 inch | 1.27 kg/mt 0.85 lb/ft | Standard |
