| Code | D.N. | Hose size | Outside Diameter | Max Working Pressure | Minimum Burst Pressure | Minimum Bend Radius | Weight | Cover Type |
|---|---|---|---|---|---|---|---|---|
| TH1SN03ICE | 5 | 4.8 mm 3/16 “ | 11.9 mm 0.47 inch | 250 bar 3620 psi | 1000 bar 14480 psi | 90 mm 3.54 inch | 0.18 kg/mt 0.12 lb/ft | Standard |
| TH1SN04ICE | 6 | 6.4 mm 1/4 “ | 13.5 mm 0.53 inch | 225 bar 3260 psi | 900 bar 13040 psi | 100 mm 3.94 inch | 0.23 kg/mt 0.15 lb/ft | Standard |
| TH1SN05ICE | 8 | 7.9 mm 5/16 “ | 15.1 mm 0.59 inch | 215 bar 3110 psi | 860 bar 12440 psi | 115 mm 4.53 inch | 0.27 kg/mt 0.18 lb/ft | Standard |
| TH1SN06ICE | 10 | 9.5 mm 3/8 “ | 17.5 mm 0.69 inch | 180 bar 2610 psi | 720 bar 10440 psi | 130 mm 5.12 inch | 0.36 kg/mt 0.24 lb/ft | Standard |
| TH1SN08ICE | 12 | 12.8 mm 1/2 “ | 20.6 mm 0.81 inch | 160 bar 2320 psi | 640 bar 9280 psi | 180 mm 7.09 inch | 0.43 kg/mt 0.29 lb/ft | Standard |
| TH1SN10ICE | 16 | 16.0 mm 5/8 “ | 23.8 mm 0.94 inch | 130 bar 1880 psi | 520 bar 7520 psi | 200 mm 7.87 inch | 0.51 kg/mt 0.34 lb/ft | Standard |
| TH1SN12ICE | 19 | 19.0 mm 3/4 “ | 27.9 mm 1.10 inch | 105 bar 1520 psi | 420 bar 6080 psi | 240 mm 9.45 inch | 0.62 kg/mt 0.42 lb/ft | Standard |
| TH1SN16ICE | 25 | 25.4 mm 1 “ | 36.0 mm 1.42 inch | 88 bar 1270 psi | 352 bar 5080 psi | 300 mm 11.81 inch | 0.93 kg/mt 0.62 lb/ft | Standard |
| TH1SN20ICE | 31 | 31.8 mm 1 1/4 “ | 43.4 mm 1.71 inch | 63 bar 910 psi | 252 bar 3620 psi | 420 mm 16.54 inch | 1.30 kg/mt 0.87 lb/ft | Standard |
| TH1SN24ICE | 38 | 38.1 mm 1 1/2 “ | 50.1 mm 1.97 inch | 50 bar 720 psi | 200 bar 2880 psi | 500 mm 19.69 inch | 1.55 kg/mt 1.04 lb/ft | Standard |
| TH1SN32ICE | 51 | 50.8 mm 2 “ | 63.5 mm 2.50 inch | 40 bar 580 psi | 160 bar 2320 psi | 630 mm 24.80 inch | 2.30 kg/mt 1.55 lb/ft | Standard |
